SH-101

$7.12

Product Information

100 lb. capacity Horizontal Hold Down Clamp. Straight Base. Slotted Toggle Bar.

Available Downloads:  2-D Drawings | 3-D Drawings

Specification
Weight: 0.068 lbs 0.03 kg
Holding Capacity: 100 lbs 445 N
Holding Capacity .56 in Front of Base: 150 lbs 667 N
Maximum Clamping Thickness: 0.94 in 23.8 mm
Throat Depth: 0.88 in 22.23 mm
Included 1:Spindle Assembly (470095):

Product Code: 80188
